Frame - 800 Series OCLV Carbon, TQ drive system, tapered head tube, rear IsoSpeed, internal routing, flat mount disc, mudguard mounts, 142x12 mm thru axle
Fork - Domane+ carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat mount disc, 12x100 mm thru
Weight - 56 – 12.85 kg/28.33 lb (with TLR sealant, no tubes)
Weight limit - This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
Battery - TQ 360Wh
Charger - TQ 4A charger
Computer - TQ LED display with Bluetooth & ANT+ connectivity
Motor - TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power
Front derailleur -Shimano 105 R7150 Di2, braze-on, down swing
Rear derailleur -Shimano 105 R7150 Di2, 36T max cog
Crank - Size: 50, 52 Praxis Carbon, 165mm length
Size: 54, 56 Praxis Carbon, 170 mm length
Size: 58, 60, 62 Praxis Carbon, 172.5 mm length
Chainring -Praxis, 50/34T, 12-speed
Cassette -Shimano 105 7101, 11-34, 12-speed
Chain -Shimano SLX M7100, 12-speed
Max. chainring size - 1x: 46T, 2x: 52/36
Wheel front -Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle
Wheel rear - Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, Shimano 11/12-speed freehub, 142x12 mm
Tyre -Bontrager Kwaremont Pro TLR, tubeless ready, folding bead, Race Dual-Compound, 120 tpi, 700x32 mm
Tyre part -Bontrager TLR sealant, 180 ml/6 oz
Max tyre size - 40 mm without mudguards, 35 mm with mudguards
Saddle -Verse Short Comp, steel rails, 145 mm width
Seatpost - Size: 50, 52, 54, 56 KVF aero carbon seat post, 20 mm offset, 280 mm length
Size: 58, 60, 62 KVF aero carbon seat post, 20 mm offset, 320 mm length
Handlebar - Size: 50, 52 Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop width
Size: 54, 56 Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width
Size: 58, 60, 62 Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width
Handlebar tape -Bontrager Supertack Perf tape
Stem - Size: 50 Trek RCS Pro, -7-degree, 80 mm length
Size: 52, 54 Trek RCS Pro, -7-degree, 90 mm length
Size: 56, 58 Trek RCS Pro, -7-degree, 100 mm length
Size: 60, 62 Trek RCS Pro, -7-degree, 110 mm length
Brake rotor -Shimano RT70, CentreLock, 160 mm
Rotor size -Max brake rotor sizes: 180 mm front, 160 mm rear
