Frame
500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle
Fork
Full carbon, tapered carbon steerer, internal brake routing, flat-mount disc, 12x100 mm chamfered thru-axle
Weight
ML – 8.64 kg/19.05 lb (with tubes)
Weight limit
125 kg (275 lb)
Shifter
Shimano 105 R7120, 12-speed
Front derailleur
Shimano 105 R7100, braze-on, down swing
Rear derailleur
Shimano 105 R7100, 36T max cog
Crank
Shimano 105 R7100, 50/34, 165 mm, 170 mm, 172.5 mm
Bottom bracket
Praxis, T47 threaded, internal bearing
Cassette
Shimano 105 7101, 11-34, 12-speed
Chain
Shimano SLX M7100, 12-speed
Max chainring size
1x: 54T, 2x: 56/43
Hub front
Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle
Skewer front
Bontrager Switch chamfered thru axle
Hub rear
Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle
Skewer rear
Bontrager Switch chamfered thru axle, removable lever
Rim
Bontrager Paradigm 23, Tubeless Ready, 24-hole, 23 mm width, Presta valve
Spokes
14 g stainless steel
Tyre
Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 170 tpi, 700x28 mm; Bontrager Aeolus Pro, Tubeless Ready, aramid bead, 120 tpi, 700x28 mm
Tyre sealant
Bontrager TLR sealant, 180 ml/6 oz
Max tyre size
32 mm
Saddle
Bontrager Aeolus Elite, austenite rails, 145 mm width
Seatpost
Madone aero carbon seat post, 0 mm offset, short length
Handlebar
Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 36/40 cm, 38/42 cm, 40/44 cm, 42/46 cm
Handlebar tape
Trek EcoTack
Stem
Trek RCS Pro, -7-degree, 80 mm, 90 mm, 100 mm, 110 mm
Brake rotor
Shimano RT70, CentreLock, 160 mm; Shimano CL700, CentreLock, 160 mm
Max brake rotor size
180 mm front, 160 mm rear
