Frame - 500 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, mudguard mounts, flat mount disc, 142x12 mm thru axle
Fork- Domane SL carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat-mount disc, 12x100 mm thru axle
Weight limit- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
Battery- Shimano BT-DN300
Charger- Charging cable included
Shifter- Shimano Ultegra R8170 Di2, 12-speed
Front derailleur- Shimano Ultegra R8150 Di2, braze-on, down swing
Rear derailleur- Shimano Ultegra R8150 Di2, 34T max cog
Crank- Size: 44, 47, 50, Shimano Ultegra R8100, 50/34, 165 mm length
Size: 52, 54, 56, Shimano Ultegra R8100, 50/34, 170 mm length
Size: 58, 60, 62, Shimano Ultegra R8100, 50/34, 172.5 mm length
Bottom bracket- Praxis, T47 threaded, internal bearing
Cassette- Shimano Ultegra R8101, 11-34, 12-speed
Chain- Shimano XT M8100, 12-speed
Max. chainring size- 1x: 48T, 2x: 52/36
Wheel front- Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12 mm thru axle
Wheel rear- Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, Shimano 11/12-speed freehub, 142x12 mm thru axle
Skewer front- Bontrager Switch thru-axle, removable lever
Skewer rear- Bontrager Switch thru-axle, removable lever
Tyre- Bontrager Kwaremont Pro GR, tubeless ready, folding bead, dual compound, 120 tpi, 700x32 mm
Tyre part- Bontrager TLR sealant, 180 ml/6 oz
Max tyre size- 38 mm without mudguards, 35 mm with mudguards (as measured, see manual for details)
Saddle - Verse Short Comp, steel rails, 145 mm width
Seatpost- Size: 44, 47, 50, 52, 54, 56, KVF aero carbon seat post, 20 mm offset, 280 mm length
Size: 58, 60, 62, KVF aero carbon seat post, 20 mm offset, 320 mm length
Handlebar- Size: 44, 47, Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 36 cm control width, 40 cm drop width
Size: 50, 52, Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop width
Size: 54, 56, 58, Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width
Size: 60, 62, Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width
Handlebar tape- Trek EcoTack
Stem- Size: 44, Trek RCS Pro, -7-degree, 60 mm length
Size: 47, Trek RCS Pro, -7-degree, 70 mm length
Size: 50, Trek RCS Pro, -7-degree, 80 mm length
Size: 52, 54, Trek RCS Pro, -7-degree, 90 mm length
Size: 56, 58, Trek RCS Pro, -7-degree, 100 mm length
Size: 60, 62, Trek RCS Pro, -7-degree, 110 mm length
Brake rotor- Shimano CL800, CentreLock, 160 mm
Rotor size- Max brake rotor sizes: 160 mm front and rear
