Frame
High-performance hydroformed alloy, Smart Routing for cables, alloy rocker link, UDH dropout, kickstand mount, ringlock mount, 120mm travel
Fork
SR Suntour XCR36-Boost, air spring, preload adjuster, lockout, 100mm, external rebound adjustment, 140mm travel
Shock
Fox Float EVOL Trunnion air shock with rebound and compression adjustment
Hub front
Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Hub rear
Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Rim
Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Schwalbe Johnny Watts 365, reflective strip, puncture protection, 65-584
Battery
Bosch PowerPack 800 Wh, smart system
Charger
Bosch standard 4A, 230V, smart system
Controller
Bosch Kiox 500, smart system
Motor
Bosch Performance Line CX
Max assist speed
15.5 mph
Shifter
Shimano Deore M5130, 10-speed
Rear derailleur
Shimano CUES U6000 GS
Crank
ProWheel alloy, 165mm length
Chainring
Alloy, with 40T narrow-wide steel ring, alloy guard
Cassette
Shimano CUES LG400, LINKGLIDE, 11-48, 10-speed
Chain
Shimano LG500, 9/10/11-speed
Pedal
VP-536 nylon platform
Saddle
Bontrager Commuter Comp
Seatpost
TranzX JD-YSI34, 100-125 mm travel, internal routing, 31.6 mm, 350-405 mm length
Handlebar
Alloy, 31.8 mm, 15 mm rise, 780 mm width
Grips
Ergotec EG Active Flex, lock on, flex adjustment
Stem
Aluminium, adjustable, 31.8 mm, Blendr-compatible, with display mount
Brake
Hydraulic 4-piston brake Magura Louise Elite Leisure
Brake rotor
Magura MDR-S, CentreLock, 203 mm
Light
Herrmans H-Black MR5-E, 140 Lumen, 40 Lux, LED, headlight; Spanninga Pimento XER
Kickstand
Pletscher Comp Flex 40
Cargo rack
MIK-compatible alloy rear rack
Weight
30.10 kg / 66.36 lbs
Weight limit
160 kg
