2026 Trek Fuel EX 9 XT Mountain Bike Sedona Red/Pennyflake Splatter

Season:2026

Brand:Trek

Code:58927RED

The fuel mx 9 XT is a playful trail bike made for hunting down side hits and chasing chaos. Its alpha next platinum aluminium frame it paired with a Fox factory suspension package (150 mm rear, 160 mm front) and mx wheels for a ride that's flickable and zippy. A mechanical Shimano XT 12-speed drivetrain gives you clean, reliable shifting and 4-piston XT m8200 brakes provide excellent modulation and stop-on-a-penny power.

Adapt, rip, repeat - only you can define your perfect trail bike that's why fuel is available in three adjustability-packed configurations. Get do-it-all capability with ex, go pop-happy with mx or charge through it all with lx.

Adjustable leverage rate - Want more bottom-out resistance without giving up small-bump sensitivity? Flip the chip in the lower shock mount for a more progressive leverage rate.

Zero stack integrated headset- With a zs standard headset, you've got loads of options for aftermarket upgrades, including angle adjust or anodised colours.

Storage and accessory mounts - Stash ride essentials with in-frame storage on all fuel models both carbon and alloy. Plus, top tube accessory mounts let you load up even more.

Fresh frame design - the fuel's new frame gives you loads of room for long dropper posts, bigger shocks, frame bags and more.

Active braking pivot - active braking pivot allows our engineers to tune how the suspension reacts to acceleration and braking forces independently. That means you get more confident control when you need it most
Technical Information
Mainframe - Alpha NEXT Platinum aluminium, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145 mm-160 mm
Fork - Fox Factory 36, Float EVOL air spring, GRIP X2 damper, 44 mm offset, Boost 110, 15 mm Kabolt X axle, 160 mm travel
Shock - Fox Factory Float X, 205 mm x 60 mm
Front Wheel - Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29"
Rear Wheel - Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru-axle, 27.5"
Rear Skewer - Bontrager Switch thru-axle, removable lever
Tyres - Maxxis Assegai, tubeless-ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5''
Maxxis Minion DHR II, tubeless-ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 27.5x2.5''
Tyre Part - Bontrager TLR sealant, 180 ml/6 oz
Max tyre size - Frame: 29x2.50", Fork: See manufacturer
Shifter - Shimano XT M8100, 12-speed
Rear Derailleur - Shimano XT M8100, long cage
Crank - Shimano XT M8120, 30T, 55 mm chain line, 170 mm length
Bottom Bracket - Shimano BB-MT501 BSA
Cassette - Shimano XT M8200, 10-51, 12-speed
Chain - Shimano XT M8100, 12-speed
Max. chainring size - Max: 34T (oval – 32T) Min: 30T (oval – 32T)
Saddle - Verse Short Comp, steel rails, 145 mm width
Seatpost - Size: S Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length
Size: M Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length
Size: XL, L Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length
Handlebar - Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width
Grips - Trek Line Elite, lock-on
Stem - Bontrager Elite, 35 mm, 0-degree, 45 mm length
Brake - Shimano XT M8200 4-piston hydraulic disc
Brake Rotor - Shimano RT86, 6-bolt, 203 mm, Shimano RT86, 6-bolt, 180 mm
Rotor size - Max brake rotor sizes – Frame: 203 mm, min 180 mm, Fork: see fork manufacturer
Weight - M - 16.91 kg / 37.29 lbs (with TLR sealant, no tubes)
Weight limit - This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
