Frame
High-performance hydroformed alloy, internal cable routing, Motor Armour, post-mount disc, 135x5mm QR
Fork
SR Suntour NEX, coil spring, preload, 50 mm travel, 100x5 mm QR
Hub front
Shimano TX505, CenterLock
Hub rear
Shimano Nexus C3001, CenterLock, 7-speed
Rim
Alex Rims DP23, alloy, 36-hole, Presta valve
Tyre
Bontrager E6 Hard-Case Lite, reflective, wire bead, 60 tpi, 700x50 mm
Battery
Bosch PowerTube 400Wh
Charger
Bosch compact 2A, 100–240V
Computer
Bosch Intuvia
Motor
Bosch Active Line Plus, 250 watt, 50 Nm, 25 km/h (15.5 mph), 32 km/h for New Zealand
Shifter
Shimano Nexus Revo, 7-speed
Crank
ProWheel alloy, 170 mm length
Chainring
ProWheel 38T narrow/wide steel, w/alloy guard
Cassette
18T
Chain
Shimano HG40, 6/7/8-speed
Pedal
VP-857
Saddle
Selle Royal Nuvola
Seatpost
Alloy, suspension, 31.6 mm, 300 mm length
*Handlebar
Size: S, M, L, XLAluminium comfortSize: S, M, L, XLAlloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Grips
Bontrager Satellite Plus
*Stem
Size: S, MBontrager alloy quill, 31.8 mm clamp, adjustable rise, Blendr-compatible, 85 mm lengthSize: L, XLBontrager alloy quill, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length
Head set
VP sealed cartridge, 1-1/8", threaded
Brake
Shimano MT200 hydraulic disc
*Brake rotor
Size: S, M, L, XLShimano EM300, CenterLock, 160 mmSize: S, M, L, XLShimano RT10, CenterLock, 160 mm
*Light
Size: S, M, L, XLSpanninga SOLO for e-bikeSize: S, M, L, XLHerrmans H-Black MR4-E, 120 Lumen, 40 Lux, LED, headlight
Kickstand
Pletscher Comp Flex 18
*Cargo rack
Size: S, M, L, XLMIK-compatible alloy rear rack, maximum load 25 kgSize: S, M, L, XLMIK-compatible alloy rack, with spring clip, maximum load 25 kg
*Mudguard
Size: S, M, L, XLEurofender TempoSize: S, M, L, XLSKS wideSize: S, M, L, XLSKS plastic, front
Weight
M - 24.05 kg / 53.02 lb (excluding battery)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
