Frame
Alpha Platinum Aluminium, PowerPack top tube, internal cable routing, 135x5mm QR
Fork
SR Suntour NEX-E25, coil spring, adjustable preload, 100mm QR, 63mm travel
Front hub
Shimano Tourney HB-QC300, Centerlock
Rear hub
Shimano FH-QC300-HM, 32-hole, Centerlock, 8/9/10/11-speed, 135x5mm
Rim
Bontrager Kovee, double-walled, Tubeless Ready, 32-hole, 23mm width, Presta valve
Tyre
Bontrager Girona Comp, sub tread puncture protection, 700x50C, made with recycled content
Battery
Bosch PowerTube 540Wh
Charger
Bosch standard 2A, 230V, smart system
Display
Bosch Purion 200
Motor
Bosch Active Line Plus, 60Nm
Maximum assist speed
25 km/h
Shifter
Shimano U4000, 9-speed
Rear derailleur
Shimano CUES U4000
Cassette
Shimano LINKGLIDE LG300, 11-46, 9-speed
Chain
Shimano LG500, 9/10/11-speed
Pedal
Nylon platform
Saddle
Bontrager Boulevard
Seatpost
Alloy, suspension, 31.6mm, 300mm length
Handlebar
Alloy, 31.8mm clamp, 15mm rise, 630mm width
Grips
Bontrager XR Endurance Comp, Lock-On
Stem
Alloy, Bontrager, 31.8mm clamp, adjustable height, Blendr compatible, 70mm or 110mm length
Headset
FSA IS-2, integrated, sealed cartridge bearing, 1-1/8" top, 1.5" bottom
Brake rotor
Shimano RT10, Centerlock, 160mm
Rear light
Spanninga SOLO for e-bike
Front light
Herrmans FL-26 Nordic CL3
Kickstand
Pletscher Comp Flex 18
Rear rack
Alloy, MIK compatible, 27kg capacity
Mudguard
SKS, plastic
Weight
24.30 kg (excluding battery and pedals)
Weight limit
136 kg (combined weight of bicycle, rider and cargo)
