Frame
Alpha Smooth Aluminium, Bosch Compact PowerTube and belt drive, internal cable routing, post-mount disc
-
Fork
Verve alloy, threadless steel steerer, ThruSkew QR
-
Hub front
Shimano Tourney HB-QC300, centerlock
-
Skewer front
132x5 mm QR, ThruSkew
-
Hub rear
Shimano Nexus C3001, coaster brake, 7-speed
-
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
-
Spokes
14 g stainless steel, black
-
Tyre
Bontrager H2 Comp, wire bead, 30 tpi, 27.5x2.00"
-
Max tyre size
650x50 mm
-
Battery
Bosch CompactTube 400 Wh
-
Charger
Bosch standard 2A, 230V, smart system
-
Computer
Bosch LED remote, smart system
-
Motor
Bosch Active, smart system, 40Nm, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC)
-
Shifter
Shimano Nexus Revo, 7-speed
-
Crank
ProWheel alloy, 170 mm length
-
Chainring
ProWheel 38T narrow/wide steel, w/alloy guard
-
Cassette
18T
-
Chain
Shimano HG40, 6/7/8-speed
-
Pedal
slip-proof pedals with reflectors
-
Max. chainring size
1x: 40T
-
Saddle
Selle Royal Nuvola
-
Seatpost
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
-
Handlebar
Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
-
Grips
Herrmans Clik, ergonomic, lock-on
-
Stem
Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 85 mm length
-
Brake
Shimano MT200 hydraulic disc
-
Brake rotor
Shimano RT10, CenterLock, 160 mm
-
Light
Spanninga SOLO for e-bike
-
Headlight
Herrmans H-Black MR5-E, 140 Lumen, 40 Lux, LED, headlight
-
Kickstand
Pletscher Comp Flex 18
-
Cargo rack
MIK-compatible alloy rear rack
-
Front rack
MIK-compatible alloy front rack, 10 kg max weight
-
Mudguard
SKS wide, plastic
-
Weight
M – 25.00 kg/55.12 lb
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
