Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Fork - SR Suntour XCR 34, air spring, 2CR damper, hydraulic lockout, tapered steerer, 44 mm offset, Boost 110, 15 mm bolt-on thru axle, 120 mm travel
Front Hub - Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Rear Hub - Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Rear Skewer - Bontrager Switch thru axle, removable lever
Rim - Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Tyre - Bontrager LT4 Expert, reflective strip, wire bead, 60 tpi, 29x2.40"
Max tyre size - Frame: 29x2.50" (S: 27.5x2.50"), Fork: see manufacturer
Battery - Bosch PowerTube 800 Wh, smart system
Computer - Bosch Purion 200
Motor - Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC)
Shifter - Shimano U6000, 10-speed
Rear Derailleur - Shimano CUES U6000 GS
Crank - FSA Bosch CK-220, 36T ring, 165 mm length
Chain Ring - FSA, 36T, steel
Cassette - Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
Chain - Shimano LG500, 9/10/11-speed
Pedal - VP-536 nylon platform
Max. chainring size - 1x: 38T
Saddle - Bontrager Commuter Comp
Seatpost - Size: S Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: M Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length
Size: L , XL Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar - Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width
Grips - Trek Line Ergonomic Comp, lock-on
Stem - Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Headset - FSA IS-2, 1-1/8" top, 1.5" bottom
Brake Rotor - Tektro, CentreLock, 203 mm
Brake Set - Tektro HD-M275 hydraulic disc
Rotor size - Max brake rotor sizes – Frame: 220 mm, min 180 mm, Fork: see fork manufacturer
Light - Supernova Mini 3 pure, LED, headlight, Supernova TL3 Mini, LED
Kickstand - Pletscher Comp Flex 18
Cargo Rack - MIK-compatible alloy rear rack
Fender - Trek Powerfly 29" custom fender
Tool - Bontrager Switch Lever, w/tool
Weight limit - This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lbs).
